Weight: 26 lbs (11.8 kgs) (including tank)

Dimensions: 18.5 x 14.5 x 7 inches

Pressure Vessel: 1/2 liter (internal); stainless steel, 4 internal cam locks

Gauges: Test Gauge, 4.5 in, white face, 0-25 bar (300 psi) or 0-40 bar (600 psi), accurate to within 1/4 of 1% full scale. Source Tank test gauge, 1.5 in, white face (0-3000 psi), part of the 3074 Quick Connect pressure supply hose assembly.

Valves: Female, CGA 580 main valve on Compressed Gas Cylinder; Metering Valve to adjust the inflow pressurization rate for uniform measurements;
Three-Way Pressure Control Valve to pressurize or to exhaust gas in the pressure vessel.

Connecting Hose: Stainless steel pressure hose with quick connect/disconnect at the PPW end and a male CGA 580 fitting on the compressed gas cylinder side.

Pressure Tank: Either 33 cu.ft. Compressed Gas Cylinder, 6.9” diameter x 15.8” length (shipped empty) or 22 cu.ft. Compressed Gas Cylinder, 5.25” diameter x 16.3” length (shipped empty)

Specimen Holder: Accepts either sealing sleeves or sealing grommets for leaves or stems using 3015G4 Specimen Holder, or use sealing plugs with the 3015G2 Specimen Holder for blade-type leaves . Has a stainless steel sealing knob and aluminum closing ring, stainless steel camlock with safety relief piston (to prevent build up in the pressure chamber unless the specimen holder is cam-locked in proper position).
